17000 BTU 208/230V Mini Split AC Heat Pump, White

Experience ultimate temperature control in your space with this 17000 BTU mini split AC, offering powerful cooling and heating for rooms up to 1250 sq.ft. This energy-efficient inverter system features smart Wi-Fi control, versatile modes, and quiet operation, making it an ideal solution for year-round comfort in homes and offices.

Overview:

• Multifunctional mini split air conditioner and heat pump system for cooling, heating, drying, and fan operation.
• Designed for large spaces up to 1250 square feet, providing powerful temperature control even in extreme conditions.
• Features smart technology for remote control via smartphone, voice, or included remote, enhancing user convenience.
• Includes energy-efficient inverter technology and R32 refrigerant for reduced environmental impact and lower operating costs.
• Note: Installation requires a licensed HVAC professional for safety and optimal performance.
• Warning: Ensure proper ventilation and follow all safety guidelines during installation and use.

Highlights:

• Powerful 17000 BTU cooling and 16500 BTU heating capacity for large rooms up to 1250 sq.ft.
• Smart Wi-Fi control compatible with Alexa and Google Assistant for remote management.
• Energy-efficient inverter technology with R32 refrigerant for eco-friendly operation.
• Versatile 7 operating modes and 7 fan speeds to customize comfort.
• Quiet sleep mode and low noise levels for undisturbed rest.
• Easy maintenance with removable, washable filter and self-cleaning function.
• Safety features like child lock and 4D auto swing to prevent direct blowing.
• Compliant with ETL and AHRI standards for reliability and performance.

Features:

• Cooling, heating, drying, and fan functions for year-round comfort.
• Inverter technology adjusts compressor speed for energy efficiency and consistent temperature.
• Smart control via smartphone, voice (Alexa/Google Assistant), and remote control with digital display.
• 7 operating modes: auto, cool, heat, dry, fan, sleep, and ECO.
• 7 fan speeds: auto, low, low-mid, mid, mid-high, high, and turbo.
• 4D auto swing to distribute air evenly and prevent direct blowing.
• Child lock for safety and I Feel mode for personalized temperature sensing.
• Health mode for improved air quality and sleep mode for quiet operation.
• Self-cleaning function at 56℃ and washable filter for easy maintenance.
• Chassis heating prevents freezing and ensures performance in cold conditions.
• 24-hour on/off timer for scheduling and screen off function in sleep mode.
• Operates in a wide temperature range: cools at up to 50℃ and heats at down to -15℃.
• Note: Installation requires a licensed HVAC professional.
• Warning: Follow all installation and safety guidelines to avoid hazards.

Weight & Dimensions:

• Indoor unit dimensions: 35.8 inches (90.9 cm) length x 11.5 inches (29.2 cm) width x 8.9 inches (22.6 cm) height.
• Outdoor unit dimensions: 32.1 inches (81.5 cm) length x 11.8 inches (30.0 cm) width x 21.5 inches (54.6 cm) height.
• Air pipe diameter: 3 inches (7.6 cm).
• Liquid pipe diameter: 1 inch (2.5 cm).
• Drain pipe diameter: 0.67 inches (1.7 cm).
• Indoor unit net weight: 24 pounds (10.9 kg).
• Outdoor unit net weight: 60.5 pounds (27.4 kg).

Specifications:

• Color: White.
• Material: Metal, aluminum, copper, and AS.
• Voltage: 208/230V~/60Hz.
• Cooling capacity: 17000 BTU.
• Heating capacity: 16500 BTU.
• Cooling power: 1770W.
• Heating power: 1440W.
• Coverage area: 1250 sq.ft (116 m²).
• Air flow volume: 412 CFM.
• Dehumidifying capacity: 81 pints per day (38.4 liters per day).
• Temperature setting range: 16℃ to 31℃.
• Refrigerant: R32.
• SEER2: 17.
• HSPF2: 8.5.
• Indoor noise level: 32 dB.
• Outdoor noise level: 57 dB.
• Max remote control distance: 39 feet (11.9 meters).
• Min. circuit ampacity: 12A.
• Note: Box quantity may vary by batch.

Package Includes:

• 1 x Indoor unit.
• 1 x Outdoor unit.
• 1 x 13 ft (4.0 m) copper connection pipe for air pipe.
• 1 x 13 ft (4.0 m) copper connection pipe for liquid pipe.
• 1 x 5.8 m (19 ft) communication wire.
• 1 x 2 m (6.5 ft) drain hose.
• 1 x Remote control.
• 1 x Wall bracket for remote control.
• 1 x Wall sleeve.
• 1 x Wall cap.
• 1 x Drain elbow.
• 1 x Tape.
• 1 x Putty.
• 1 x User guide.

Package Quantity: 2 boxes.
